Rectangularity values of the Blobs obtained by dividing the areas of the Blobs by their minimum circumscribed rectangles’ areas.

LEDtvclipart

Validation result Boolean list of the output Blobs. The validation rules are set by the parameters under “Validation Settings”.

Circularity values of the Blobs obtained by dividing the areas of the Blobs by the areas of circles whose perimeters are the perimeters of the Blobs.

2D transformation input at this port is used to transform the ROI set in a previous execution to the appropriate position.

Led clipartblack and white

This Step binarizes the input image, detects Blobs in the image, calculates their contours, pixel-wise areas, circularities, and rectangularities, and validates the Blobs one by one according to the set standard.
