Infrared Light Inspection (NIR)
Product Details of Infrared Light Inspection (NIR) for Sale
-
Features:
-
1.Strong penetration, wavelength optional: 850/940nm.
2.Use with high sensitive CCD of near infrared field.
3.Use with infrared glass filter, adapt to strong ambient light applications.
-
Applications:
-
1.Monitoring.
2.Packing ( through the plastic packing).
3.Foreign matter of wine bottle inspection.
4.Electronic, semiconductor inspection.
Spectrum chart
Illumination property diagram
Imaging instance：lingerie buckles inspection
Coding rule
|
|
|
|
|
|
| Ring infrared light | LTS-RN5060-NIR | .png) |
Out dia. φ50,Inner Dia. φ20,Height 9mm | 24V | 1.2W |
| LTS-RN7090-NIR | |
Out dia. φ60,Inner Dia. φ30,Height 11mm | 24V | 2.6W | |
| LTS-RN12030-NIR | |
Out dia. φ74,Inner Dia. φ38,Height 9mm | 24V | 4.4W | |
| Coaxial infrared light | LTS-3COX40-NIR | |
Out dia. φ120,Inner Dia. φ86,Height 28mm | 24V | 1.5W |
| LTS-3COX50-NIR | |
Out dia. φ146,Inner Dia. φ128,Height 25mm | 24V | 2.4W | |
| Back infrared light | LTS-4FT5050-NIR | |
Out dia. φ40,Inner Dia. φ16,Height 18mm | 24V | 2.4W |
| LTS-4FT7070-NIR | |
Out dia. φ50,Inner Dia. φ25,Height 25mm | 24V | 3.9W | |
| LTS-4FT8080-NIR | |
Out dia. φ60,Inner Dia. φ35,Height 25mm | 24V | 4.4W | |
| LTS-4FT100100-NIR | |
Out dia. φ70,Inner Dia. φ33,Height 20mm | 24V | 7.7W | |
| LTS-4FT150150-NIR | |
Out dia. φ74,Inner Dia. φ40,Height 20mm | 24V | 11.6W | |
| Bar infrared light | LTS-4BR6016-NIR | |
Out dia. φ43,Inner Dia. φ20,Height 13mm | 24V | 1.0W |
| LTS-4BR9016-NIR | |
Out dia. φ50,Inner Dia. φ20,Height 22mm | 24V | 1.5W | |
| LTS-4BR18016-NIR | |
Out dia. φ70,Inner Dia. φ38,Height 21mm | 24V | 2.9W | |
| LTS-4BR7530-NIR | |
Out dia. φ90,Inner Dia. φ56,Height 20.5mm | 24V | 2.2W | |
| LTS-4BR12530-NIR | |
Out dia. φ100,Inner Dia. φ60,Height 22mm | 24V | 3.6W | |
| * UV & IR light can be customized as required. | |||||
*If you need drawings, please contact the sales staff.
