Is methane a flammablegas

Nothing in this document is intended to prevent the use of methods or materials of equivalent or superior quality to those prescribed below.  The E2RC will review documented requests for equivalency.

5.2.9.3        “Crash buttons” shall be provided to accomplish the shutdowns described above.  These devices shall be conveniently located, and one shall be adjacent to the fire alarm panel, if present.  Crash buttons should shut off all flammable gas sources which could conceivably be confused by unfamiliar person in a state of panic.  Crash buttons shall be labeled “Gas System and Experiment Power Shutdown.”  They shall be located on the Building Evacuation Plan Maps.

5.2.9        Flammable gas detectors shall be installed near equipment installations, mixing stations, and in storage sheds (the measures in this requirement are not necessary for outdoor storage applications):

list of flammable gases - wikipedia

5.3.1        Storage and processing enclosures shall be constructed, where practical, to comply with the guidelines of Chapter 7 Liquefied Petroleum-Gas Liquid Transfer of NFPA-58 (see Flammable Gas Supplement Chapter 3 Standard for the Storage and Handling of Liquefied Petroleum Gases) While this document is specifically applicable only to LP gas storage facilities, it is a useful guide.  Exceptions may be made with the written approval of the E2RC.

3.1              An analysis of the gas system shall be conducted using the flowchart shown in Figure 1.  The analysis is based on the energy in the gas available for a fire, and classifies gas systems in order of increasing risk.  The flowchart in Figure 1 utilizes the limits on quantities of hydrogen gas.  These quantities must be adjusted for other gases using the heat of combustion as described in Flammable Gas Supplement Chapter 7 Heats of Combustion.  The results of the analysis indicate the Gas System Class as described in Table 1.

5.2.6        Provisions shall be made to purge the entire system with an inert gas.  If vacuum pumps are used for this, they shall be listed for flammable gas service.

Most flammablegaslist

The gas system class analysis shall be reviewed by the Physics Division Experimental ES&H Review Committee (E2RC) or by an independent reviewer appointed by the committee, in which case a copy of the independent review shall be sent to the E2RC.  Approval by the Physics Division Safety Officer is required before the introduction of flammable gas into a system.

5.2.9.1        A low level alarm no higher than 10% of the lower explosive limit (LEL) shall sound a local alarm and be used to initiate corrective action according to a plan included in the documentation of system operating procedures.

5.1.6        Enclosed volumes containing piping or equipment shall be incapable of becoming pressurized.  For example, chest freezers shall not have latching doors.  Electrical devices enclosing or enclosed within these volumes shall be listed for use in Class 1, Division 2 locations per NEC Article 500 or otherwise be documented and approved as non-sparking devices.

Examples of gas systems analysis are given in Flammable Gas Supplement Chapter 2 Examples of Gas System Class Determination.

5.2.11    Possible Oxygen Deficiency Hazards shall be addressed according to ES&H Manual Chapter 6540 Oxygen Deficiency Hazard (ODH) Control Program.  The hazard shall be considered for each building or room using or storing flammable or inert gas.

We will resume accepting applications in January 2025. Please check back at this time to submit your request via the required form. Any inquiries submitted via email will receive a response in January 2025.

Flammable and inflammable gases

5.2.12.7       A call list, including home telephone numbers and available pagers, of personnel familiar with the operation of the system.

5.2.12.4       A plan view of the installation including the locations of flammable gas detector heads with their elevations marked.

The use of flammable gases in physics experiments presents a unique type of installation, requiring special considerations.  In many cases, mixing of gases is involved.  Large volumes of gases may be present; thus even small leaks or ruptures of thin windows may cause incursions into the flammable concentration region with a large inventory to support fire.  Some flammable gases may be stored in the liquid state, increasing the inventory.  Electrical equipment is an integral part of such installations and can thus provide an ignition source if such a system is improperly designed, fabricated, or operated.  The purpose of this procedure is to mitigate the hazards associated with storage and use of flammable gases.

3.2              The upper limit for a Class 0 gas system is the combustion energy in 0.6 kg of hydrogen.  The equivalent quantities of some typical flammable gases are given in Table 2.  This equivalence is scaled according to the heat of combustion of the gas.

5.1.1        The area shall be posted “Danger-Flammable Gases, No Ignition Sources” using standard signs available from the Jefferson Lab Safety Lab (in Building 35 or by contacting the Physics Division ES&H Staff).  A list of responsible persons with their phone numbers shall also be posted.

Procedures are the same as for Class 0, with the addition that if an independent reviewer or review panel is appointed, the E2RC must formally concur with the report of that review.  Approval by the Division Associate Director is required before the introduction of flammable gas into a system.

Flammable gases list

5.1.5        All gas cylinders shall be secured.  Cylinders not in use shall be capped.  Empty cylinders shall be removed at the earliest convenient date or on a predetermined, regular schedule coordinated with vendor delivery of new cylinders.  See also ES&H Manual Chapter 6150 Compressed, Liquefied, and Solidified Gas Program.

5.2.9.2        A high level alarm no higher than 25% of the lower explosive limit (LEL) shall summon the Newport News Fire Department through the Jefferson Lab fire alarm network.  This high level alarm shall also automatically shut off the supply of flammable gas and turn off power to potential ignition sources within 10 feet or three meters of operative gas usage apparatus.

5.1.4        An orifice, excess flow valve or other fixed means of limiting the flow to no higher than ten times the maximum operational flow rate shall be installed.

5.3.2.6        Electrical installation shall comply with NEC Article 500, Hazardous (Classified) Locations.  The classification guidelines are provided in Flammable Gas Supplement Chapter 4 Electrical Classification Guidelines and Flammable Gas Supplement Chapter 5 Electrical Installation.

3.3              Installations may be subdivided into separable parts if restrictions exist to keep the gas flow from one part to another from exceeding ten times the normal flow rate.  Normally, the separable parts will be in physically separate rooms.  The gas system Class shall be determined for each installation or separable part thereof using Figure 1.

5.2.7        Pressure relief devices shall be provided to limit the pressure to the maximum working pressure in various parts of the system.  In the case of low pressure equipment, dedicated bubblers may be used as relief devices.  Common exhaust piping (where the flammable gas vent is shared with exhaust vents for other systems) shall not be used if equipment overpressure from any combination of devices sharing the exhaust could result due to built up back pressure.

Flammablegaspropane

Flammable Gases may be diluted with inert gas to the point where the mixture is not flammable.  This standard does not apply to facilities using only non-flammable mixtures if they are pre-mixed and verified when obtained.  If a malfunction of an on-site mixing apparatus could cause a mixture to become flammable, the standard does apply to the worst case scenario.  The flammability of a mixture can be determined by referencing United States Department of the Interior Bureau of Mines Bulletins 503 and 627.  Contact the Physics Division ES&H Group for copies of these bulletins or the reference section in the Jefferson Lab library.

5.1.8        Ventilation above one air change per hour shall be maintained in areas using or storing flammable gas if normal operational flow rates are less than 5 Standard Cubic Liters Per Minute (SCLM).  This ventilation may be accomplished by mechanical or natural ventilation.  For natural ventilation a room vent with a minimum of 1/2 square foot of free area shall be provided per 1000 cubic feet of room volume.  If normal operational flow rates are greater than or equal to 5 SCLM, supervised mechanical ventilation in accordance with Section 7-2.2.1(a) of NFPA 58 Liquefied Petroleum Gas Code, 2004 edition shall be provided (not applicable to outdoor Jefferson Lab storage).
