Our DR-SP3W recessed LED spotlights with 3W output in warm white complement our complete LED sets and are ideal for illuminating our patio canopies. The compact lights for indoor and outdoor use are supplied with a 5 metre connection cable.

WARNING: The recessed LED spotlights may only be connected to an S-Polylight LED power controller with 12V output voltage using the connection cables supplied. It is not recommended to use a different 12 V power supply unit for the power supply. Never connect the spotlights directly to a 230V line. There is a danger to life. Electrical connections should only be made by qualified personnel.
