Ring light is a circular lighting tool generally used in photography and videography. It allows even illumination with very few shadows, creating the right result for portraits, macro photography, and video content creation. The light source surrounds the camera lens to provide balanced lighting on the subject.

LED Backlight for TV that changes with picture

Conversely, if the LED pitch is smaller than the distance to the cover, the individual LEDs will blend seamlessly, but there may be a lumen loss. To achieve the desired luminous flux for the application, more LEDs or an increase in current would be needed, which may impact energy efficiency and component lifespan.

Put a ring light right in front of the subject, which can evenly light it up. Adjust the brightness and color temperature according to the environment. Add a diffuser when it gets too hard. Tweak angles and distances for different effects. Make sure to check the photo for unwanted reflections or glare.

At our company, all the LED strips offered are covered with a highly reflective white resist layer, ensuring optimal performance and luminous flux.

Backlight LED

For optimal results, the distance between the LEDs and the cover should be equal to the LED pitch. For instance, if the LED pitch is 10 mm, the distance between the LEDs and the cover should also be 10 mm. This principle applies to various backlighting applications, including linear LED fixtures, LED strips in aluminum profiles, or LED tubes.

LCD backlight

Reflective sheet: Placing a reflective sheet with 98.8% reflectance on top of the LED strip can boost the flux by up to 2.4%. In the case of a 2000 lm/m linear LED fixture, this results in an increase of 48 lm/m compared with a highly reflective resist layer. The reflective sheet enhances the overall light output by reflecting and redirecting the light emitted from the LEDs.

The choice between a ring light and a key light depends entirely on your needs. A ring light does an excellent job for shots that need to be close-up with even lighting, while a key light can show dramatic effects since it allows changes in direction. Consider what type of content you create. If you shoot beauty or macro photographs, then you will most likely want to make use of ring lights. If the goal is more cinematic or professional video, then a key light would be the better choice.

Under lighting

If the LED pitch is larger than the distance to the cover, the individual LED's emission light will become increasingly noticeable as the difference between the two grows. This results in undesirable hotspots, compromising the uniformity and overall appearance of the backlighting.

Put a ring light right in front of the subject, which can evenly light it up. Adjust the brightness and color temperature according to the environment. Add a diffuser when it gets too hard. Tweak angles and distances for different effects. Make sure to check the photo for unwanted reflections or glare.

White PCB: Selecting an LED strip with a white printed circuit board (PCB) can also contribute to increased luminous flux. The white PCB acts as a reflective surface that reduces light absorption, enhancing the overall light output from the LEDs.

Ring lights have several advantages, including providing soft, even lighting with few shadows and accentuated details. This further improves the skin in portraits and creates beautiful catchlights in the subject's eyes. Also, ring lights are quite versatile and can be used for beauty shots, video blogging, and close-up photography.

Buy a ring light that fits your needs, considering the size and the adjustment of brightness. You can find options offering adjustable color temperature that allows you to adapt to different lighting environments. Consider whether you need a portable option in case you need to move your ring light around a lot. Ensure that it will work with your camera and see if there are additional features, such as the capability to mount your smartphone or dim the light.

Backlit lighting photography

LED backlighting is a popular and versatile lighting solution that can be used in various applications, from linear lighting fixtures to luminous ceilings and illuminated signs. Achieving the perfect balance of total luminous flux and individual LED visibility is crucial for successful implementation. This article delves into the essential aspects of selecting and positioning LEDs for backlighting applications, ensuring optimal performance while meeting project requirements.

To achieve seamless backlighting, it is essential to consider factors such as LED pitch and the distance between the LEDs' emitting surfaces and the diffuse cover.

Back light computer

LED pitch (L) refers to the distance between the centers of adjacent LEDs on a strip or fixture. The relationship between LED pitch and the distance from the LEDs to the diffuse cover plays a critical role in achieving uniform backlighting.

Increasing the total luminous flux is essential for achieving the desired brightness levels in your backlighting application. Two strategies can be employed to enhance the flux:

Achieving the perfect balance between total luminous flux and individual LED visibility is crucial for the success of any backlighting application. By understanding and applying the principles of LED pitch, distance to the cover, and techniques to maximize luminous flux, you can create visually stunning and efficient backlighting solutions for linear lighting fixtures, luminous ceilings, and illuminated signs.

Keep in mind that selecting the right LED products and working with reputable suppliers can make all the difference in the quality, performance, and longevity of your LED backlighting projects. Invest time in research, planning, and collaboration to ensure your backlighting applications truly shine.

LED backlighting involves placing light-emitting diodes (LEDs) behind a diffuse cover to create uniform and visually appealing illumination. Common applications include:
