Explosion-proof or hazardous location cord reels are engineered to prevent sparks that could cause fires or explosions. They feature a spark-resistant ratchet mechanism and an explosion-proof slip ring enclosure. These reels are certified for use in environments where flammable and explosive materials are present, such as in mining operations, grain storage facilities, and manufacturing plants that produce fuels, fertilizers, paints, or explosives.

Open cord reels are designed without an enclosure, providing direct access to their internal parts. They are typically used in light-duty applications and are suited for environments where corrosion is not a concern.

To use the cord reel, pull out the desired length of cord to make the necessary electrical connections; this extended position is known as the payout position. Connect the equipment plug to the receptacles on the cord reel or at the end of the cable. The excess cord remains coiled on the drum. When the cord is no longer needed, the winding mechanism will automatically retract and rewind the cord onto the drum, keeping it organized and ready for the next use.

Manual cord reels are operated using a hand crank that rotates the reel drum to extend the electrical cord. To rewind the cord onto the reel, you turn the crank in the reverse direction. These reels are suited for lightweight or shorter cables, as the manual process of winding and unwinding is relatively easy. They are portable, cost-effective, and commonly used in indoor settings like homes, offices, and retail spaces.

Substations & High Voltage: turnkey, unitized & modular substations, mobile substations. Switchgear: metal enclosed, medium voltage, full range of custom options. Pad-Mt Primary Metering. Capacitor & Harmonic Filter Banks: metal enclosed, medium voltage, full range of custom options. Custom transformers and reactors. Custom, metal enclosed products and packages.

A metering pump is a precision mechanical device that moves or pumps a measured amount of a fluid or liquid in a predetermined time period to create an accurate and exact volumetric flow...

Cord reels feature a cylindrical drum designed to hold and manage extension cords. The drum is equipped with two large flanges or discs on either end to keep the cord securely wound. This drum is mounted on a frame that includes various accessories, such as brackets and bases, allowing it to be attached to floors, ceilings, posts, walls, carts, or equipment.

When purchasing live connection cord reels, ensure that the reel comes with a cord of adequate length and the necessary connection hardware. It’s crucial to verify that the reel matches the required amperage, voltage rating, and plug and socket type to ensure reliable power transmission from the mains to your equipment.

Wide range of instrument transformers in accordance with IEEE STD C57.13. High Voltage station service transformers up to 167kVA at 138kV.

Cord reel enclosures are often rated according to standardized systems. The manufacturer usually provides the specific rating for the enclosure, which indicates its level of protection.

Retractable cord reels are often installed centrally to streamline the workspace. They can be mounted on ceilings, walls, or workbenches. Commonly found in service garages, machine shops, and manufacturing facilities, these reels help keep the work area organized and efficient.

Low profileExtension Cord

Cord reels are used to manage and store extension cords that provide power to electrical equipment or devices situated at a distance from power outlets. They help in keeping long extension cords organized and prevent tangling or damage when not in use.

Motor-driven cord reels feature a motor to assist in winding the cord onto the reel drum. They are particularly useful when significant retraction force is required. These reels operate at slow speeds and maintain consistent tension on the cord, helping to prevent overstretching and potential damage.

Medical cord reels are specifically engineered for use in healthcare environments such as hospital wards, operating theaters, emergency departments, medical labs, and radiology suites. They are also utilized in mobile clinics and portable laboratories.

SCADA, Distribution Management (DMS), Outage Management (OMS) & Substation HMI. NEW: FLISR (Fault Location, Isolation, Restoration); GIS Wizard; SmartVU 3.0 with advanced OMS & DMS.

Cord storage reels are designed to neatly wind and store extension cords. They typically include a reel drum and a frame with various mounting accessories, while the extension cord itself is purchased separately. Most of these reels are operated manually using a hand crank. They are ideal for keeping extension cords safe and well-maintained when not in use. However, they are meant solely for storage purposes and should not be used while the cord is energized. Always ensure the cord is fully unwound from the reel before plugging it in.

A hose reel is a mechanism for storing and use of a hose on a barrel for easy access. It is a system designed to make hoses, cords, flexible tubing, and wire conveniently available for immediate use...

The typical installation configurations for cord reels vary based on their intended use. This factor is crucial when choosing the right cord reel for your needs.

Flat PlugExtension CordHome Depot

Consider the operating environment of the cord reel when making your selection. A robust enclosure or casing is essential for protecting the internal components from damage caused by moisture, corrosion, dust, and debris. Enclosures help ensure the cord reel’s performance and reliability, especially in outdoor or harsh conditions. Consequently, enclosed cord reels are generally preferable to open models.

Lastly, consider your budget when selecting a cord reel. Opt for a reel that offers the necessary features and specifications while staying within your financial limits.

360° rotating flat plugextension cord

Cord reels are widely used across various industries to extend the lifespan of power and extension cords. They help prevent tangling and nesting, protecting the cords from wear, abrasion, and damage by allowing only the required length to be exposed for electrical connections. Additionally, cord reels enhance safety by reducing tripping hazards associated with cluttered cables. By choosing the appropriate type, specifications, and installation method for a given application, cord reels provide both convenience and practicality, making them a valuable investment for efficient and safe cord management.

Rotating PlugExtension Cord

Cord reels are commonly constructed from materials such as plastic (e.g., PVC, ABS), fiberglass, stainless steel, and aluminum. Metal cord reels are typically used for thicker, heavier cords and often feature anti-corrosion coatings to endure outdoor and harsh conditions. Plastic cord reels, suited for lighter cords, are generally used indoors. Premium cord reels may be designed to be water-resistant, non-sparking, dust-proof, and resistant to shock and vibration, making them suitable for extreme environmental conditions.

Stainless steel cord reels are typically made from grade 304 stainless steel, known for its superior mechanical properties, including high strength and durability, as well as excellent resistance to corrosion. These reels are ideal for use in industries such as food processing, pharmaceuticals, and healthcare, where maintaining hygiene and preventing contamination are critical. Additionally, other sectors can also take advantage of the robust performance and longevity offered by stainless steel cord reels.

Live connection cord reels enable continuous electrical flow through the cord even when part of it is still wound on the reel. These reels are equipped with connection hardware that includes electrical sockets. A crucial element for these reels is the collector ring, which ensures smooth operation while the cord remains live. The collector ring is responsible for delivering power and electrical signals necessary for the reel drum's rotation.

The first consideration when choosing a cord reel is the type and specifications of the cord it will accommodate. It's essential to determine the cord's outer diameter, length, bend radius, and gauge before selecting a reel. These dimensions impact the size of the reel required; larger and thicker cords necessitate a bigger reel. Additionally, the weight of the cord should be factored in, as heavier and longer cords may need an automatic retraction system to handle the increased effort and save time and labor.

In a retrieve configuration, the cord reel is attached to mobile equipment, with the cord’s free end secured to a stationary point. As the reel moves away from the anchor, the cord unwinds and extends. When the reel moves back towards the anchor, the cord retracts. Strong spring tension is necessary to ensure the cord retracts quickly enough to keep pace with the moving equipment.

Hot-line Meters measure current to 5000A in environments of 500kV, voltage up to 37,000V, direction of current flow, and power factor. Recorders for primary load and power quality studies.

In a lift configuration, a stationary cord reel is fixed to a wall or ceiling above the work area. The cord is lowered vertically either manually or using a mechanism. The reel is built to support the weight of the cord and the outlet box, so it must be constructed from robust materials. A ratchet mechanism ensures that the cord stays in place when extended. This setup is commonly used in manufacturing environments and retail stores.

Lighted cord reels have an attached lamp at the free end of the power cord. The light source may be an incandescent, fluorescent, or LED lamp. The cord is pulled at the desired length, and the lamp is hung on a ceiling or wall above the area being observed. The light from the lamp may be directed flexibly for optimal lighting.

flat plugextension cord3-prong

These reels are commonly employed in heavy-duty scenarios, including outdoor and remote locations like mines, tunnels, refineries, construction sites, and water treatment facilities.

Flatextension cordfor under rug

Commercial cord reels are optimally designed for light-duty applications. They are used in environments where corrosion is unlikely to occur. They are usually made of non-metallic material or stainless steel and are portable. They are commonly found in classrooms, offices, retail stores, and others.

Comprehensive generator, transmission, and distribution protection; distribution automation; control systems; telecommunications; precision timing; custom panels and enclosures; custom engineering services. NEW: Blueframe DMA & FLISR; SEL-T401L Ultra-High-Speed Line Relay; RTAC Axion Bay Controller w/ touchscreen; SEL-735 Touchscreen PQ Meter!

Solid dielectric and SF6 switchgear; Reclosers; Automatic-Transfer Controls and fault interrupters; cable terminations & joints; epoxy products including encapsulated switches, current limiting fuses, junction bars, apparatus bushings, transition modules, and splice boxes. NEW: Viper-HV 72kV Recloser!

The certification and inspection of cord reels are conducted in accordance with UL 355, also known as the UL Standard for Safety Cord Reels. A UL certification indicates that a cord reel meets stringent safety and performance standards. Cord reels that have been certified by UL often display a UL mark to signify their compliance with these rigorous criteria.

Cable reels hold conductive cable or lifting cable and are used for storage, unwinding, and winding. Contacts on electric cable reels keep the power on while winding. Reels are machines that wrap long, continuous goods like cable...

The connection hardware should provide enough electrical outlets to support all your devices. Consider safety features such as sockets with grounding terminals for added protection. Some cord reels are equipped with automatic circuit breakers to safeguard against short circuits and current surges. Additionally, certain models offer USB ports for convenient charging of devices.

Underwriters Laboratories (UL) is an independent safety organization headquartered in Northbrook, Illinois. UL’s team of experts tests and assesses various electrical products, including cord reels, to identify potential hazards.

A two-digit code is assigned to each electrical enclosure. The first digit indicates the protection from foreign bodies and particulates. Meanwhile, the second digit indicates the protection from moisture and immersion in water. The digit is replaced by “X” if the enclosure is unrated or offers no protection.

A lubricant is a substance that is applied on surfaces that have relative motion in between them. The lubricant reduces friction and wears between the surfaces. However, the lubricant can have other...

Ultra Thin FlatExtension Cord

Power transformers and shunt reactors, up to 765 kV 2050 kV BIL, 2,200 MVA capacity. Gas Insulated Switchgear up to 800 kV. NEW: Battery Energy Storage Systems (BESS); STATCOM; New transformer factory in Tennessee.

Choosing the right cord reel can significantly boost productivity and enhance safety in your workspace. With a variety of designs available, it's important to consider the following factors to select the most suitable cord reel for your specific needs:

Retractable cord reels automatically pull the cord back to the reel drum, making them easier to operate than manual cord reels. They use a spring mechanism to provide the retraction force. As the cord is uncoiled and pulled out for use, tension builds up on the steel torsion spring. Once the electrical power is no longer needed, the stored energy in the torsion spring is released, retracting the cord back to the reel.

In a stretch configuration, the cord extends horizontally with some sag and no support. The reel can be either stationary or mobile and is typically mounted on the ceiling or high up on a wall. The cord should be 10% longer than the distance from the reel to the workstation to account for the sag.

These cord reels help prevent tripping hazards and ensure a stable power supply to medical equipment, which is crucial for patient safety. They usually feature a spring-driven retraction system and are housed in a robust, durable casing. The materials used in medical cord reels are selected for their ease of cleaning, waterproof properties, resistance to corrosion, and antimicrobial characteristics.

Newell Porcelain, a decades long preferred manufacturer and supplier of solid core station posts has expanded their product line to include overhead line products. Now supplying a full line of porcelain and glass suspensions and porcelain distribution porcelain, with design ratings 7.5kV to 765kV, Newell has among the broadest porcelain offerings in the US Market.

Motor-driven cord reels can be powered by electric, hydraulic, or pneumatic motors. Electric motors, which use either AC or DC power from an electrical outlet, are straightforward to use, cost-effective, and efficient. Hydraulic and pneumatic motors, powered by pressurized liquids and compressed air, respectively, are ideal for environments lacking direct power sources. They are designed to avoid overheating under load and are suitable for areas with high fire and explosion risks.

As the cord is extended, it moves through a gap between two roller guides that steer its direction. These rollers are made from smooth materials to minimize cord wear. A ratcheting system locks the reel drum at various positions to maintain the desired length of the cord. A stopper, larger than the clearance, is positioned near the cord's end to secure it when fully retracted. Additionally, the guide arm adjusts the angle at which the cord is paid out.

In a vertical pick-up configuration, the cord reel is mounted on a machine component that moves up and down. The power source is located above the reel drum at the end of the cord. As the machine moves, the reel coils or releases the cord accordingly. Adequate spring tension is required to manage the cord’s upward movement into the reel.

IP Rating System. IP (Ingress Protection) ratings are used to classify electrical enclosures based on their sealing effectiveness against unwanted intrusion of foreign bodies and moisture. They indicate the suitability of the device for use in a specific environment. IP ratings are assigned per EN 60529 or IEC 60509.

Substation hook-stick operated disconnect and 3-phase group-operated disconnect switches; complete line of power connectors. NEW: 5000 double end break and aluminum side break switches.

Lubrication systems distribute the lubricant to the moving machine parts in contact. Lubricants reduce the friction between sliding or rolling machine elements, such as gears, spindles, bearings, chains, dies, screws, cylinders, valves, and...

Lighted cord reels are perfect for outdoor environments and locations lacking nearby power sources. They are also useful indoors, such as in service garages, where they provide additional lighting to illuminate the workspace.

Doble offers products from the following subsidiaries: Vanguard Instruments, Morgan Schaffer, Manta Test Systems, Enoserv

The required cord length must be estimated in order to select the live connection cord reel, which covers the distance between the power source and the workstation. The following are the operating parameters of cord reels pertaining to the required cord length:

In a drag configuration, the cord reel is mounted on a wall or post slightly above the floor. The cord is pulled horizontally from the reel, either manually or by machinery, as it remains on the ground. A ratchet mechanism secures the cord once it is extended. This configuration allows for flexible extension over longer distances as the cord moves horizontally.
