Technical data and downloadsZoom Factor1,5x2x4x8xOrder No663991*663992*663993*663994*Data sheet (pdf) - one for allFix-BEX 355nm.pdfFix-BEX 355nm.pdfFix-BEX 355nm.pdfFix-BEX 355nm.pdfSTEP data (stp)Fix-BEX 355nm 1,5x.stpFix-BEX 355nm 2x.stpFix-BEX 355nm 4x.stpFix-BEX 355nm 8x.stpZemax-BlackboxFix-BEX 663991.zipFix-BEX 663992.zipFix-BEX 663993.zipFix-BEX 663994.zip *available soon; please contact us for delivery time information

where is positive and is negative if the incident and diffracted beams are on opposite sides of the grating surface normal, as illustrated in the example in Figure 2. If the beams are on the same side of the grating normal, then both angles are considered positive.

Polarization Dependence:Surface gratings that have high groove densities also have an issue with polarization dependent loss, often with significantly lower efficiency when exposed to parallel- versus perpendicularly-polarized light. Volume phase holographic gratings are designed for applications that require low polarization dependent loss at higher spatial frequencies.

This beam expander is designed for a wavelength of 355 nm and offers a large input aperture of up to 8 mm (1/e2). It offers clear and stable laser power and can be used with a 1.5x, 2x, 4x or 8x expansion factor at high powers. The high-precision optical design ensures diffraction-limited imaging and prevents internal foci. It also comes with a divergence setting as standard. The housing is made of stainless steel for maximum resistance and durability, and the optical elements are made of robust quartz glass with AR coating. For use in its reverse mode, the beam expander is threaded on both sides.

Optimized coatings ensure the highest transmission and lowest thermal influences. To ensure durability and a high destruction threshold in high-power laser applications, we use full quartz as the lens material.

Technical data and downloadsWavelength1030...1080 nm515...540 nm355 nmOrder No611842627445613266Datenblatt (pdf) -one for allBEX-M 1x-8x.pdfBEX-M 1x-8x.pdfBEX-M 1x-8x.pdfSTEP-Datei (stp) -one for allBEX-M 1x-8x.stpBEX-M 1x-8x.stpBEX-M 1x-8x.stpZemax-Blackbox (zip)BEX-M 1x-8x 611842.zipBEX-M 1x-8x 627445.zipBEX-M 1x-8x 613266.zip

Please note that dispersion is based solely on the number of grooves per mm and not the shape of the grooves. Hence, the same grating equation can be used to calculate angles for holographic as well as ruled blazed gratings.

Reflective grating master copies are made by depositing a metallic coating on an optic and ruling parallel grooves in the surface. Thorlabs' reflective gratings are made of epoxy and/or plastic imprints from a master copy, in a process called replication. In all cases, light is reflected off of the ruled surface at different angles corresponding to different orders and wavelengths. All of Thorlabs' ruled reflective diffraction gratings exhibit a sawtooth profile, also known as blazed, while our reflective holographic diffraction gratings exhibit a sinusoidal profile. For more information, please refer to the Gratings Tutorial tab.

Whether manually or variably adjustable or motorized, the beam expanders of the BEX product families are robust, flexible and durable.

Beam expanderlens

A focus ring allows the divergence of laser beams to be changed in a targeted manner, thus compensating for the focal length tolerances in the overall system. This also makes it possible to change the position of the working plane according to the scanning system.

The Littrow configuration refers to a specific geometry for blazed gratings and plays an important role in monochromators and spectrometers. It is the angle at which the grating efficiency is the highest. In this configuration, the angle of incidence of the incoming and diffracted light are the same, = , and > 0 so

Beam Expandergymnastics

While blazed gratings offer extremely high efficiencies at the design wavelength, they suffer from periodic errors, such as ghosting, and relatively high amounts of scattered light, which could negatively affect sensitive measurements. Holographic gratings are designed specially to reduce or eliminate these errors. The drawback of holographic gratings compared to blazed gratings is reduced efficiency.

With the motorized beam expander 1x-8x, Jenoptik helps you adapt to market requirements by optimizing and balancing the critical parameters of time, quality and ease of use. Consequentially, the motorized beam expander is a perfect match for the F-Theta lenses of Jenoptik’s SilverlineTM series and can be used in a variety of beam guidance systems.

Resolving Power:The resolving power of a grating is a measure of its ability to spatially separate two wavelengths. It is determined by applying the Rayleigh criteria to the diffraction maxima; two wavelengths are resolvable when the maxima of one wavelength coincides with the minima of the second wavelength. The chromatic resolving power (R) is defined by R = λ/Δλ = n*N, where Δλ is the resolvable wavelength difference, n is the diffraction order, and N is the number of grooves illuminated. Due to their low groove density, Echelle gratings provide high resolving power.

Jenoptik’s Fix-BEX product line offers the right solution for applications that do not require changes to the zoom factor.

where both and are positive if the incident and diffracted beams are on opposite sides of the grating surface normal, as illustrated in the example in Figure 1. If they are on the same side of the grating normal, must then be considered negative.

One popular style of grating is the transmission grating. The sample diffraction grating with surfaces grooves shown in Figure 1 is created by scratching or etching a transparent substrate with a repetitive series of narrow-width grooves separated by distance . This creates areas where light can scatter.

Settings can also be conveniently locked. Therefore, influences such as vibrations or system accelerations system are minimized. In addition, the BEX 1x-4x Steadfast stands for easy maintenance and minimal set-up times.

The blazed grating, also known as the echelette grating, is a specific form of reflective or transmission diffraction grating designed to produce the maximum grating efficiency in a specific diffraction order. This means that the majority of the optical power will be in the designed diffraction order while minimizing power lost to other orders (particularly the zeroth). Due to this design, a blazed grating operates at a specific wavelength, known as the blaze wavelength.

The Littrow configuration angle, , is dependent on the most intense order ( = 1), the design wavelength, , and the grating spacing . It is easily shown that the Littrow configuration angle, , is equal to the blaze angle, , at the design wavelength. The Littrow / blaze angles for all Thorlabs' Blazed Gratings can be found in the grating specs tables.

Stray Light:Due to a difference in how the grooves are made, holographic gratings have less stray light than ruled gratings. The grooves on a ruled grating are machined one at a time which results in a higher frequency of errors. Holographic gratings are made through a lithographic process, which generally creates smoother grating masters free of tool marks. Replicants made from these masters exhibit less stray light. Applications such as Raman spectroscopy, where signal-to-noise is critical, can benefit from the limited stray light of the holographic grating.

The 1x-8x beam expanders are part of the SilverlineTM high-power lens series and are designed in such a way that a diffraction-limited image quality is achieved over the entire magnification range.

The desired grating pattern is comprised of a repetitive series of lines separated by distance . The fringe planes for transmission gratings are perpendicular to the plane of the plate as seen in Figure 8, allowing any frequency of light to pass through the plate. Diffraction occurs as incoming light crosses through the DCG film. Therefore, the three major factors that determine performance are film thickness, bulk index (the average index of refraction between Bragg planes), and index modulation (the difference of index of refraction between the Bragg planes). The incident light enters the grating at an angle of , as measured from the surface normal. The light of order exiting the grating leaves at an angle of , relative to the surface normal. The grating expression mentioned above can be used to calculate diffraction angles for volume phase holographic gratings since dispersion is based on the line density. The quality of the grating is determined by the fringe contrast, with a poor fringe contrast resulting in low efficiency or no grating at all.

The BEX 1x-4x variable beam expanders for the wavelengths 355 nm, 532 nm and 1030...1080 nm provide a high image quality with their compact lengths. All versions are infinitely adjustable between a 1x and 4x expansion factor. The larger the expanded beam, the smaller that structures can be created with the paired F-Theta objective.

The 0th order reflection from a blazed grating is shown in Figure 4. The incident light at angle is reflected at for = 0. From Eq. 3, the only solution is = –. This is analogous to specular reflection from a flat surface.

Beam expanderOptics

Diffraction gratings, either transmissive or reflective, can separate different wavelengths of light using a repetitive structure embedded within the grating. The structure affects the amplitude and/or phase of the incident wave, causing interference in the output wave. In the transmissive case, the repetitive structure can be thought of as many tightly spaced, thin slits. Solving for the irradiance as a function wavelength and position of this multi-slit situation, we get a general expression that can be applied to all diffractive gratings when = 0°,

This issue can be resolved by creating a repeating surface pattern, which produces a different surface reflection geometry. Diffraction gratings of this type are commonly referred to as blazed (or ruled) gratings. More information about this can be found in the section below.

For further information about gratings and selecting the grating right for your application, please visit our Gratings Tutorial.

Caution for Gratings with Surface Grooves:The surface of a diffraction grating with surface grooves can be easily damaged by fingerprints, aerosols, moisture or the slightest contact with any abrasive material. Gratings should only be handled when necessary and always held by the sides. Latex gloves or a similar protective covering should be worn to prevent oil from fingers from reaching the grating surface. Solvents will likely damage the grating's surface. No attempt should be made to clean a grating other than blowing off dust with clean, dry air or nitrogen. Scratches or other minor cosmetic imperfections on the surface of a grating do not usually affect performance and are not considered defects. Conversely, volume phase holographic gratings can be cleaned using standard optics cleaning procedures and have high durability.

The blazed grating features geometries similar to the transmission and reflection gratings discussed thus far; the incident angle () and th order reflection angles () are determined from the surface normal of the grating. However, the significant difference is the specular reflection geometry is dependent on the blaze angle, , and NOT the grating surface normal. This results in the ability to change the diffraction efficiency by only changing the blaze angle of the diffraction grating.

Beam expandercalculator

known as the grating equation. The equation states that a diffraction grating with spacing will deflect light at discrete angles (), dependent upon the value λ, where is the order of principal maxima. The diffracted angle, , is the output angle as measured from the surface normal of the diffraction grating. It is easily observed from Eq. 1 that for a given order , different wavelengths of light will exit the grating at different angles. For white light sources, this corresponds to a continuous, angle-dependent spectrum.

The specular reflection from the blazed grating is different from the flat surface due to the surface structure, as shown in Figure 5. The specular reflection, , from a blazed grating occurs at the blaze angle geometry. This angle is defined as being negative if it is on the same side of the grating surface normal as . Performing some simple geometric conversions, one finds that

Beam expanderfor sale

Figure 6 illustrates the specific case where = 0°, hence the incident light beam is perpendicular to the grating surface. In this case, the 0th order reflection also lies at 0°. Utilizing Eqs. 3 and 4, we can find the grating equation at twice the blaze angle:

Thorlabs offers two types of transmission gratings: ruled and volume phase holographic. The ruled transmission gratings are created by scratching or etching a transparent substrate with a repetitive, parallel structure, creating areas where light can scatter. These gratings have a sawtooth diffraction profile and are made of epoxy and/or plastic imprints from a master copy, in a process called replication. Our volume phase holographic diffraction gratings consist of a dichromated gelatin (DCG) film between two glass substrates. These gratings have a sinusoidal wave diffraction pattern written on the DCG film using a laser setup. For more information, please refer to the Gratings Tutorial tab.

The BEX 2x-10x variable beam expanders for the wavelengths of 355 nm, 532 nm and 1030...1080 nm have a particularly large zoom range. All versions have an infinitely adjustable zoom factor between 2x and 10x.

Beam ExpanderThorlabs

Unlike traditional gratings, volume phase holographic (VPH) gratings do not have surface grooves. Instead, VPH gratings consist of a dichromated gelatin (DCG) film between two glass substrates. These VPH gratings are designed to reduce the periodic errors that can occur in blazed gratings. Surface gratings with high groove density also have an issue with polarization dependent loss. These unique transmission gratings deliver high first-order diffraction peak efficiency, low polarization dependence, and uniform performance over broad bandwidths.

The first issue with using higher order diffraction patterns is solved by using an Echelle grating, which is a special type of ruled diffraction grating with an extremely high blaze angle and relatively low groove density. The high blaze angle is well suited for concentrating the energy in the higher order diffraction modes. The second issue is solved by using another optical element: grating, dispersive prism, or other dispersive optic, to sort the wavelengths/orders after the Echelle grating.

Beam expanderdesign

Another very common diffractive optic is the reflective grating. A reflective grating is traditionally made by depositing a metallic coating on an optic and ruling parallel grooves in the surface. Reflective gratings can also be made of epoxy and/or plastic imprints from a master copy. In all cases, light is reflected off of the ruled surface at different angles corresponding to different orders and wavelengths. An example of a reflective grating is shown in Figure 2. Using a similar geometric setup as above, the grating equation for reflective gratings can be found:

Laserbeam expander

The DCG film is taken through multiple quality control steps to ensure it performs up to standard and then cut into the desired size. The film is sealed between two glass covers to prevent degradation of the material. Since the DCG film is contained between two glass substrates, VPH gratings have high durability and long lifetimes, as well as easy maintenance compared to other gratings that can be easily damaged.

Thanks to corresponding software interfaces, the motorized beam expander can be easily integrated into any system for laser material processing.

These beam expanders are specifically designed for applications where widened beam diameters are required. The larger the expanded beam, the smaller the structures can be produced with a paired F-Theta objective lens.

Both the reflective and transmission gratings suffer from the fact that the zeroth order mode contains no diffraction pattern and appears as a surface reflection or transmission, respectively. Solving Eq. 2 for this condition, = , we find the only solution to be =0, independent of wavelength or diffraction grating spacing. At this condition, no wavelength-dependent information can be obtained, and all the light is lost to surface reflection or transmission.

It is easily observed that the wavelength dependent angular separation increases as the diffracted order increases for light of normal incidence (for = 0°, increases as increases). There are two main drawbacks for using a higher order diffraction pattern over a low order one: (1) a decrease in efficiency at higher orders and (2) a decrease in the free spectral range, , defined as:

Blaze Wavelength:Ruled gratings have a sawtooth groove profile created by sequentially etching the surface of the grating substrate. As a result, they have a sharp peak efficiency around their blaze wavelength. Holographic gratings are harder to blaze, and tend to have a sinusoidal groove profile resulting in a less intense peak around the design wavelength. Applications centered around a narrow wavelength range could benefit from a ruled grating blazed at that wavelength.

Do not leave reliable beam guidance to chance but to a competent partner. Jenoptik’s beam expanders offer extensive optical know-how and many years of application expertise.

The blaze wavelength is one of the three main characteristics of the blazed grating. The other two, shown in Figure 3, are , the groove or facet spacing, and , the blaze angle. The blaze angle is the angle between the surface structure and the surface parallel. It is also the angle between the surface normal and the facet normal. Note that Figure 3 also defines the direction of the "blaze arrow"; this arrow is visibly marked on one edge of all Thorlabs' blazed transmission gratings.

The BEX 1x-4x steadfast beam expanders are characterized by a mechanical design that guides the movable optical elements in a stable, linear manner. This reduces the influence of mechanical manufacturing irregularities and increases beam stability whenever changing magnification and/or divergence. This ensures a beam direction stability of less than one milliradian.

The Fix-BEX 515...540 nm demonstrates its advantages for applications in the FIS sector. It has excellent directional stability and thus consistently offers high beam quality. Like all other versions, it offers a large input aperture of up to 8 mm (1/e2) and diffraction-limited imaging. Internal foci are prevented thanks to the sophisticated high-precision optic design. The divergence of the laser beam can also be adjusted. The optical elements are made of robust quartz glass with AR coating. In addition, the Fix-BEX can be used in reverse mode, as the beam expander is threaded on both sides.

Dear user, your browser has JavaScript turned off or an installed extension (for example, NoScript) is blocking the execution of Javascript. If you want to use our services without restriction, please enable Javascript in your browser settings. Thank you for your understanding.

The incident light impinges on the grating at an angle , as measured from the surface normal. The light of order exiting the grating leaves at an angle of , relative to the surface normal. Utilizing some geometric conversions and the general grating expression (Eq. 1) an expression for the transmissive diffraction grating can be found:

Efficiency:Ruled gratings generally have a higher efficiency than holographic gratings. Holographic grating tend to have a lower efficiency but a broader effective wavelength range. The efficiency of ruled gratings may be desirable in applications such as fluorescence excitation and other radiation-induced reactions.

Holographic gratings are made from master gratings by similar processes to the ruled grating. The master holographic gratings are typically made by exposing photosensitive material to two interfering laser beams. The interference pattern is exposed in a periodic pattern on the surface, which can then be physically or chemically treated to expose a sinusoidal surface pattern. An example of a holographic grating is shown in Figure 9.
