The area across which your camera can image is known as the field of view or FOV, the larger the FOV the more of your sample you can see. Having a large FOV allows you to take more efficient images containing more data, and take fewer images in order to capture the entire sample. But as with all camera specifications, changes to FOV will affect other vital factors such as resolution and imaging speed.

If the goal is simply to attach the camera to the microscope, a 1x adaptor contains no additional lenses and provides no additional magnification or demagnification. This is often the preferred method as it introduces no additional lenses into the system. Every extra lens reduces the number of photons reaching the camera by 3-4% so many researchers will try to avoid this.
