IntroductionHello all! Welcome on board. Here we are going to focus on designing a 5V power supply. We will design the power supply and carry out and explain how to do various calculations including all the necessary steps. The main objective of this article is to share know-how and ensure that at the end of the project tutorial, you have enough lessons to allow you the ability to design your power supply according to your specifications and requirements. This project guide will take you through every design step including the design mathematics for example if we have a capacitor in our schematic, we should end up knowing why it exists where it is and how we sized it.Project RequirementAt the end of this project guide, we shall be able to:Design a 5V DC output voltage power supply with an input of 220V AC, an output current of 250mA, and 3% ripple factor.The power supply should have over-current and overvoltage protection features.The design should have reverse-bias protection.Design load and line voltage regulations should be in the 3% range.Let us start with the complete design guide.Power Supply Universal Block DiagramIn general, the block diagram of a power supply is made up ofThe Input TransformerRectifier CircuitFilterVoltage RegulatorLet us have a look at the block diagram and what each element in the block diagram does before doing the actual design.Figure 1: Power Supply General Block DiagramEach section of the block diagram has a specific function and we have to go deeper into that so that we can know why the sections exist.Input TransformerTransformers have the function of stepping up or stepping down the circuit voltages and this is guided by the energy conservation law.In our circuit, we shall be employing a step-down transformer so that depending on your country we can lower the input voltage from 220V to something closer to 5V which is our project requirement.The Rectifier CircuitThe transformer stepped-down voltage remains to be AC. To convert the voltage to DC, the rectifier circuit is employed in converting the AC to DC, and without it becomes very impossible to have our 5V DC output.Rectifier circuits exist as integrated circuit packages, but you can design your full-wave rectifier using four diodes.Remember we have half-wave and full-wave rectifiers, but our circuit design interest is in full-wave rectifiers.Voltage FilterThe rectifier does the conversion of AC to DC but this conversion does not give a purely DC output. The rectifier output is in pulsation. This is known as pulsating DC.The pulsating DC is never good for powering most sensitive electronic devices since it is noisy, and corrupted with ripples.A filter is used in the circuit to remove the pulses and ripples, making the voltage compatible with the voltage regulator.A good filter should reduce the ripples to lower than 10% for perfect voltage regulation and the best filter we can use for the project is the capacitor which is a charge-storing.Voltage RegulatorA voltage regulator is a perfect device that is used when a regulated constant output voltage is required. This ensures that the output voltage does not change even if the load or line voltages change.Figure two below summarizes the happenings in the block diagram in Figure 1.Figure 2: Power Supply Block Diagram and Graphical Analysis5V DC Linear Power Supply Circuit DiagramFigure 3: 5V DC Power Supply Schematic Using KiCAD EDAFigure 3 above shows the circuit diagram for our project. The main power supply is 220 Vrms at a frequency of 50Hz but this depends on your country’s regulations. The fuse is used to protect the circuit, the transformer for stepping down voltage, the rectifier, the filter capacitor, the LED used as an indicator, and the voltage regulation IC.The circuit is implemented and simulated using KiCAD EDA, open-source software good for professional and educational PCB design.From the circuit, we shift to a step-by-step power supply design.Power Supply Step-by-Step Design Method At this stage, we shall design every stage mentioned above and assemble them to have a complete design at the end.At this stage, we shall design every stage mentioned above and assemble them to have a complete design at the end.Step 1: Voltage Regulator IC the same datasheet, a connection circuit is available with a 0.1uF capacitor placed at the output side for protection against load changes and transient voltage. At the input, side is a connection of the 0.33uF capacitor to protect the regulator against ripples.

Hello all! Welcome on board. Here we are going to focus on designing a 5V power supply. We will design the power supply and carry out and explain how to do various calculations including all the necessary steps. The main objective of this article is to share know-how and ensure that at the end of the project tutorial, you have enough lessons to allow you the ability to design your power supply according to your specifications and requirements. This project guide will take you through every design step including the design mathematics for example if we have a capacitor in our schematic, we should end up knowing why it exists where it is and how we sized it.
