Human eyesfocal length

In many applications, the required distance from an object and the desired FOV (typically the size of the object with additional buffer space) are known quantities. This information can be used to directly determine the required AFOV via Equation 2. Equation 2 is the equivalent of finding the vertex angle of a triangle with its height equal to the WD and its base equal to the horizontal FOV, or HFOV, as shown in Figure 2. Note: In practice, the vertex of this triangle is rarely located at the mechanical front of the lens, from which WD is measured, and is only to be used as an approximation unless the entrance pupil location is known.

When using fixed focal length lenses, there are three ways to change the FOV of the system (camera and lens). The first and often easiest option is to change the WD from the lens to the object; moving the lens farther away from the object plane increases the FOV. The second option is to swap out the lens with one of a different focal length. The third option is to change the size of the sensor; a larger sensor will yield a larger FOV for the same WD, as defined in Equation 1.

Focaldistance vsfocal length

Psichiatra e psicoanalista, è Professore ordinario alla Sapienza Università di Roma. Tra i suoi ultimi libri: L’ombelico del sogno (Einaudi 2023); Arcipelago N. Variazioni sul narcisismo (Einaudi 2021); Diagnosi e destino (Einaudi 2018). Ha ricevuto numerosi premi, tra cui il prestigioso Sigourney Award (2023). Collabora con varie testate.

The focal length of a lens is a fundamental parameter that describes how strongly it focuses or diverges light. A large focal length indicates that light is bent gradually while a short focal length indicates that the light is bent at sharp angles. In general, lenses with positive focal lengths converge light while lenses with negative focal lengths cause light to diverge, although there are some exceptions based on the distance from the lens to the object being imaged.

If the required magnification is already known and the WD is constrained, Equation 3 can be rearranged (replacing $ \small{ \tfrac{H}{\text{FOV}}} $ with magnification) and used to determine an appropriate fixed focal length lens, as shown in Equation 6.

(Napoli, 18 aprile 1953) è un artista che ha lavorato anche come giornalista. È stato vicedirettore di Repubblica. Ha esposto in molte gallerie italiane e straniere, e in numerosi spazi pubblici: nel 2020 la Galleria Nazionale di Roma ha ospitato una sua personale. Ha scritto “Pollock e Rothko, il gesto e il respiro” (Einaudi Stile Libero, 2020), e “Paul Klee, genio e regolatezza”, (Laterza 2022).

The 14.25° derived in Example 1 (see white box below) can be used to determine the lens that is needed, but the sensor size must also be chosen. As the sensor size is increased or decreased it will change how much of the lens’s image is utilized; this will alter the AFOV of the system and thus the overall FOV. The larger the sensor, the larger the obtainable AFOV for the same focal length. For example, a 25mm lens could be used with a ½” (6.4mm horizontal) sensor or a 35mm lens could be used with a 2/3” (8.8mm horizontal) sensor as they would both approximately produce a 14.5° AFOV on their respective sensors. Alternatively, if the sensor has already been chosen, the focal length can be determined directly from the FOV and WD by substituting Equation 1 in Equation 2, as shown in Equation 3.

focallength中文

Generally, lenses that have fixed magnifications have fixed or limited WD ranges. While using a telecentric or other fixed magnification lens can be more constraining, as they do not allow for different FOVs by varying the WD, the calculations for them are very direct, as shown in Equation 4.

Knowledge Center/ Application Notes/ Imaging Application Notes/ Understanding Focal Length and Field of View

Note: Horizontal FOV is typically used in discussions of FOV as a matter of convenience, but the sensor aspect ratio (ratio of a sensor’s width to its height) must be taken into account to ensure that the entire object fits into the image where the aspect ratio is used as a fraction (e.g. 4:3 = 4/3), Equation 7.

Another way to change the FOV of a system is to use either a varifocal lens or a zoom lens; these types of lenses allow for adjustment of their focal lengths and thus have variable AFOV. Varifocal and zoom lenses often have size and cost drawbacks compared to fixed focal length lenses, and often cannot offer the same level of performance as fixed focal length lenses.

A fixed focal length lens, also known as a conventional or entocentric lens, is a lens with a fixed angular field of view (AFOV). By focusing the lens for different working distances (WDs), differently sized field of view (FOV) can be obtained, though the viewing angle is constant. AFOV is typically specified as the full angle (in degrees) associated with the horizontal dimension (width) of the sensor that the lens is to be used with.

Focal lengthformula

In general, however, the focal length is measured from the rear principal plane, rarely located at the mechanical back of an imaging lens; this is one of the reasons why WDs calculated using paraxial equations are only approximations and the mechanical design of a system should only be laid out using data produced by computer simulation or data taken from lens specification tables. Paraxial calculations, as from lens calculators, are a good starting point to speed the lens selection process, but the numerical values produced should be used with caution.

Be aware that Equation 6 is an approximation and will rapidly deteriorate for magnifications greater than 0.1 or for short WDs. For magnifications beyond 0.1, either a fixed magnification lens or computer simulations (e.g. Zemax) with the appropriate lens model should be used. For the same reasons, lens calculators commonly found on the internet should only be used for reference. When in doubt, consult a lens specification table.

Lavinia Guillari flauto Marco Ignoti clarinetti Valentino Corvino | Ruben Medici violino Corrado Carnevali viola Sebastiano Severi violoncello Stefano Malferrari pianoforte Nunzio Dicorato percussioni

FOV tofocal length

The focal length of a lens defines the AFOV. For a given sensor size, the shorter the focal length, the wider the AFOV. Additionally, the shorter the focal length of the lens, the shorter the distance needed to obtain the same FOV compared to a longer focal length lens. For a simple, thin convex lens, the focal length is the distance from the back surface of the lens to the plane of the image formed of an object placed infinitely far in front of the lens. From this definition, it can be shown that the AFOV of a lens is related to the focal length (Equation 1), where $ \small{f} $ is the focal length and $ \small{H} $ is the sensor size (Figure 1).

Note: As the magnification increases, the size of the FOV will decrease; a magnification that is lower than what is calculated is usually desirable so that the full FOV can be visualized. In the case of Example 2, a 0.25X lens is the closest common option, which yields a 25.6mm FOV on the same sensor.

focallength是什么

Once the required AFOV has been determined, the focal length can be approximated using Equation 1 and the proper lens can be chosen from a lens specification table or datasheet by finding the closest available focal length with the necessary AFOV for the sensor being used.

\begin{align}\text{AFOV} & = 2 \times \tan^{-1} \left( {\frac{50 \text{mm}}{2 \times 200 \text{mm}}} \right) \\ \text{AFOV} & = 14.25° \end{align}

Il Novecento è il secolo in cui finiscono le certezze. La teoria della relatività e la scoperta dell’inconscio annunciano un mondo che non sarà più lo stesso. Rileggere tempo, spazio e psiche significa trasformare per sempre anche l’esperienza creativa, dando vita a nuovi modi di dipingere, scrivere, scolpire, recitare, girare un film e comporre musica. E a nuovi modi di vivere e pensare. È in questo mondo in trasformazione che nasce la parola “avanguardia”, a indicare ciò che anticipa e rinnova, inevitabilmente opponendosi alla tradizione. Il concetto di avanguardia è riconducibile solo ai suoi movimenti più noti e “storicizzati” (espressionismo, futurismo, dadaismo, surrealismo) o può esprimersi in ogni forma artistica finendo inevitabilmente per infrangere la sua stessa definizione? Da Picasso a Buñuel a Schönberg proveremo a raccontare – rivolgendoci all’arte, alla scienza e alla psicoanalisi – come visioni e percezioni trasformate abbiano saputo decostruire il corpo, riabilitare il mondo onirico, rivoluzionare le idee di suono e linguaggio, mettendo in discussione l’idea stessa di arte. I concetti di avanguardia e neo-avanguardia hanno accompagnato e attraversato il secolo scorso fino ai giorni nostri portando con sé turbamento e trasformazione, illuminazioni prodigiose e ombre oscure, inevitabilmente toccando il mondo non solo dell’arte ma anche della politica. E oggi, nel nuovo millennio, ha ancora senso parlare di avanguardie?

Example 2: For an application using a ½” sensor, which has a horizontal sensor size of 6.4mm, a horizontal FOV of 25mm is desired.

Equivalentfocal lengthcalculator

Field of view describes the viewable area that can be imaged by a lens system. This is the portion of the object that fills the camera’s sensor. This can be described by the physical area which can be imaged, such as a horizontal or vertical field of view in mm, or an angular field of view specified in degrees. The relationships between focal length and field of view are shown below.

Focal length

FontanaMIX ensemble nasce nel 2002 con un concerto per il Bologna Festival inaugurando un progetto in cui interpreti e compositori lavorano in stretta collaborazione alla produzione di nuove opere musicali e multimediali. Nell’ambito del progetto EXITIME, da oltre vent’anni FontanaMIX dedica ogni anno un ritratto monografico ad una importante figura del panorama compositivo internazionale, sia attingendo dal repertorio (Bussotti, Berio, Donatoni, Ligeti, Harvey, Rihm, Crumb) che lavorando a stretto contatto con i grandi artisti della nostra epoca come Sofia Gubaidulina, Salvatore Sciarrino, Fausto Romitelli, Kaija Saariaho, Tristan Murail, Ivan Fedele, Alessandro Solbiati, Lukas Ligeti. L’ensemble si è esibito in alcune delle più importanti sale e rassegne concertistiche italiane ed europee: Cité de la Musique di Strasburgo, Teatro Comunale di Bologna, Teatro Massimo di Palermo, Maggio Musicale Fiorentino, Istituto di Cultura giapponese a Roma, MAMbo e Goethe-Zentrum a Bologna, Filarmonica di Rovereto; i festival “Tone Generation” di Malmö, “Demetria” di Salonicco, “Aperto” di Reggio Emilia, “Angelica” di Bologna, “Musica d’oggi” di Aquiterme e la Biennale Musica di Venezia; le rassegne “Milano Musica” e “Rondò” di Milano, “Nuova Consonanza” di Roma, Amici della Musica e “Curva Minore” a Palermo, “Trieste Prima”, “Rive Gauche” di Torino, “Musica@Villa Romana” a Firenze, “Aosta Classica”,“Tempo d’orchestra” a Mantova, “Ravenna Musica”, Associazione Musicale Etnea di Catania. Nel 2014 ha inaugurato il Festival “Nuove Musiche” del Teatro Massimo di Palermo eseguendo il capolavoro “Vortex temporum” di Gérard Grisey. Nel 2020 FontanaMIX ha realizzato per la Biennale di Venezia “Sette canzoni per Bruno” un concerto/ documentario dedicato ai 100 anni della nascita di Bruno Maderna. Dal 2014 collabora con l’ensemble Accroche Note realizzando un gemellaggio culturale fra le città di Strasburgo e Bologna. Nel 2021 ha realizzato insieme al Das Neue Ensemble di Hannover un progetto di circuitazione di nuovi autori europei. Oltre che da Francesco La Licata, FontanaMIX è stato diretto da Yoichi Suiyama e Marco Angius, e ha collaborato con diversi artisti quali i cantanti Monica Bacelli, Cristina Zavalloni, Valentina Coladonato, Nicholas Isherwood, Roberto Abbondanza, i pianisti Mauro Castellano, Fabrizio Ottaviucci e Andrea Rebaudengo, la flautista Annamaria Morini, il violinista Paolo Chiavacci, i violoncellisti Frances-Marie Uitti e Francesco Dillon, il contrabbassista e compositore Stefano Scodanibbio, i fisarmonicisti Claudio Jacomucci e Corrado Rojac, la chitarrista Elena Casoli, il coreografo Luca Veggetti. Dal 2021 è in residenza presso la Ex-chiesa San Mattia di Bologna (col supporto della Sovrintendenza dei Beni Culturali) con il progetto “Officine San Mattia” in cui realizza le produzioni ed ospita alcuni dei più importanti artisti della scena contemporanea, dalla musica alla danza alla video-arte. Dal 2004 al 2009 è stato ensemble in residenza presso il Dipartimento di Musica e Spettacolo dell’Università di Bologna realizzando concerti, progetti didattici e laboratori sul repertorio contemporaneo anche nelle sue espressioni legate all’innovazione tecnologica.

While it may be convenient to have a very wide AFOV, there are some negatives to consider. First, the level of distortion that is associated with some short focal length lenses can greatly influence the actual AFOV and can cause variations in the angle with respect to WD due to distortion. Next, short focal length lenses generally struggle to obtain the highest level of performance when compared against longer focal length options (see Best Practice #3 in Best Practices for Better Imaging). Additionally, short focal length lenses can have difficulties covering medium to large sensor sizes, which can limit their usability, as discussed in Relative Illumination, Roll-Off, and Vignetting.

While most sensors are 4:3, 5:4 and 1:1 are also quite common. This distinction in aspect ratio also leads to varying dimensions of sensors of the same sensor format. All of the equations used in this section can also be used for vertical FOV as long as the sensor’s vertical dimension is substituted in for the horizontal dimension specified in the equations.

Note: Fixed focal length lenses should not be confused with fixed focus lenses. Fixed focal length lenses can be focused for different distances; fixed focus lenses are intended for use at a single, specific WD. Examples of fixed focus lenses are many telecentric lenses and microscope objectives.

As previously stated, some amount of flexibility to the system’s WD should be factored in, as the above examples are only first-order approximations and they also do not take distortion into account.
